10X10 DSP DANTE
Model name: DSP-AEC-1010-DAAUDIO DSP WITH AEC, 4-IN/4-OUT ANALOG, 4-IN/4-OUT DANTE AND USBThe DSP-AEC-1010-DA is an audio signal processing unit with analog and Dante interface, as well as a USB for computer audio.
The unit is configured and controlled from a Windows application that presents an easy to use GUI. Powerful processing with eq, dynamics, mixing and matrix combined with advanced acoustic echo cancellation (AEC) makes this unit suitable for a wide range of use cases.
A single network cable connected to a PoE network switch allows for both power, control and Dante audio. Analog audio inputs supports both microphone and line level sources. Phantom power is selectable individually for each channel.
USB connection to host computer works as a sound card for easy computer audio connectivity for both playback and recording.
Processor
ADI SHARC 21489
Sample rate/bit depth
48kHz/24bit
Input gain steps
0/6/12/18/24/30/36/42/48dB
Phantom Power
48V
Frequency Response (20Hz~20KHz)
±0.5dB
Maximum Level
+18dBu
THD + Noise
0.003%@4dBu
Dynamic Range
110dB
Background Noise (A-weighted)
-91dB
Common Mode Rejection Ratio @60Hz
80dB
Channel Isolation @1KHz
108 dB
Input Impedance (Balanced Connection)
5.6kΩ
Output Impedance (Balanced Connection)
102Ω
System Delay
<3ms
Power Requirements
PoE or 12V
Power Adapter
AC110~240V 5Hz-60Hz, 12V DC / 2A output
Maximum Power Consumption
10W
Dimensions (Width x Depth x Height)
215 x 162 x 44mm
Shipping Weight
2 kg
- Papildus informācija
-
Papildus informācija
Garums, cm 0 Platums, cm 0 Height, cm 0 Energijos sąnaudų klasė #N/D Ražotājs TIGHT AV Ražotāja kods DSP-AEC-1010-DA Ražošanas valsts Svītrkods 202210210002 User's manual Download Gross weight, kg 2 Neto svars, kg 1.9 Package Height, cm 7.0000 Package Width, cm 25.0000 Package Depth, cm 53.0000 Iepakojuma tilpums, m3 0.0093 Komentārs biznesa klientiem #N/D - Apskati
-
